When 3M rolled out their True Definition Scanner, I was the first dentist in the U.S. to have one delivered. The True Def is the successor to 3M's first scanner effort, the Lava Chairside Oral Scanner. During the pitch, Sarah (my 3M sales rep) claimed over and over that agreements with companies like Biomet 3i and Straumann and Invisalign were forthcoming, and that I would be able to use the scanner for all sorts of things in the coming months.
As we all know, sales reps say a lot of things that may or may not ever come to pass. The last thing I expected was for all these connections to become reality, including a partnership between 3M True Def scanner and Invisalign. Invisalign also owns Cadent, the maker of iTero. I guessed that Invisalign would want to push clinicians in the direction of their scanner, not open up to the others. Guess who was wrong? Me!
The first "workflow" on my True Def that I used, other than for traditional fixed prosthodontics, was for Invisalign. In order to scan Invisalign cases, clinicians must go through a training protocol with 3M. A total of five practice scans must be submitted to the 3M training lab, which are then reviewed. Once certified, the ability to submit scans to Invisalign is turned on remotely by 3M. The scanning itself is not any different than any other scan. Obviously a full mouth scan is required. All the surfaces of all the teeth should be captured along with 2 to 3 mm of gingiva. Once everything is captured, the scan is submitted to Invisalign. After the scan is uploaded, a prescription can be entered at the Invisalign website like normal.
Once 3M clears you to submit scans, the company notifies Invisalign that you are scanning-ready. When you submit your Invisalign prescription, a new page opens that asks if you are submitting by scan or PVS impression. If submitting by scan, you select that option. The Invisalign system will automatically retrieve the scan. Finish your prescription like normal, and you're done!
I've noticed that ClinChecks from scans usually come back in about two days, which is much faster than with PVS impressions. Aligner fit seems to have improved as well. Better aligner fit should mean more predictable movements and finishes. I think that this is a strong addition to the repertoire of the 3M True Definition Scanner.
Pros: Quick ClinCheck turnaround, better-fitting aligners, less expensive than iTero
Cons: Some learning curve to getting good full-mouth scans, powder required
Final thoughts: If you already have a True Def scanner and are an Invisalign provider, this is a no-brainer. If you don't have a scanner and are looking to buy one just for Invisalign, the price point of the True Def is better than that of the iTero. Using a scanner you already bought for indirect fixed restorations for Invisalign and getting good results is a homerun! To add to the benefits of using this system and the connections that come along with it, 3M just announced a major upgrade that includes a new, even smaller and faster wand, along with new scanning software. Look for the upgrade to be available this fall.
